YFC-D型液压蝶阀测试机 |
|
1 压力表
Pressure meter
|
3 按钮板
Button board
|
5 活塞杆
Piston rod
|
7 低压水泵
Low pressure water pump
|
9 高压水泵
High pressure water pump
|
2 时钟
Clock |
4 压力表开关
Pressure meter switch |
6 压爪
Press claw |
8 液压油箱
Hydraulic oil tank |
10 工作盘
Working disc |
| YFC-D外型结构示意图(单式)YFC-D overall structure schematic diagram (single) | |
 |
